1. Control Panel :
- Logic controller, complete auto fuction and standard wiring.
- Complete automatic, no adjustment is required.
2. Pre-Cooler :
- Combined with air-to-refrigerant condenser by a heat insulation area. Compact of high
technologies.
- Excellent inlet air distribution results in ghig performance and low pressure drop.
3. Pressure Control :
- Pre-set type pressure switch (HPS & LPS) in used for better stability and fewer
malfunctioning.
- Reset type high pressure switch (HPSM) is specially designed for models larger than J2E-75
to
prevent compressor from overloading.
4. Refrigeration Compressor :
- Hermetic, High performance and efficiency.
- CE Certified.
- Class F, IP53.
5. Electronic :
- Timer control with manual drain test.
- Anti-blockage by a large ball valve.
- Driven by motor, no more coil burnt down concern.
6. Pressure Vessel :
- Stainless steel pressure vessel, antirust and life extend.
- Compact TWO-IN-ONE design : Air-to-air heat exchanger combine with evaporator.
- Leak test by high precision instrument, leakage free in guaranteed.
- CNS manufacturing standard ; CE, ASME, CSQL, standard upon request.
7. Evaporator :
- Wave type aluminum fins with diversion plate increases the contact surface of air and
refrigerant. The lower by-pass and higer cooling efficiency is easy to achieve. |
